Always-on, space-saving solution with extreme-narrow bezels
See an immersive and dependable viewing experience, 24/7 with Samsung’s VMB-U series. The display’s slim depth and 500 nit brightness ensures highly visible images and legible messages in a wide range of locations from shopping malls to lobbies, meeting rooms, control rooms and more.
Transform any space with high impact visuals
The slender design and 69.9mm (2.75 inches) cabinet depth provide flexibility for installation and an ultra-narrow 3.5mm bezel-to-bezel width creates a seamless picture opening endless possibilities for designing a captivating visual experience.
View content from any angle
Wide viewing angles mean content is easily visible even if viewers aren’t standing directly in front of the display. Audiences can get clear details and vivid colors regardless of where the screen is located.
Vibrant images in any light
Non-glare panels evenly distribute light across the screen to maintain vibrant and accurate content. Combined with a high contrast ratio and 24/7 operation, visuals are vivid and eye-catching any time of the day or night—regardless of ambient light.
Image enhancement
Samsung’s powerful picture enhancement technology ensures all content is vibrant and clear. With Picture Enhancer mode, color saturation and contrast are improved by adjusting the gamma curve. Using Black Equalizer mode, dark images are lightened, making details easier to see.
Comprehensive calibration to fit your needs
Multi-step factory tuning provides uniform brightness and color. Users can also fine-tune advanced settings with free powerful Color Expert Pro software. For quick and simple calibration, Color Expert Pro Mobile enables white balance adjustments for displays up to 5x5 using a mobile camera.
Advanced presentation, simplified operation
Utilizing daisy chain design through DisplayPort 1.2 or HDMI ports enables the display to present UHD content on multiple screens without an external graphic card. Samsung's UHD Signage Player Box streamlines functionality by combining the media player and content management software.
Durable and user-friendly design
IP5x certified, the VMB-U series is dust-resistant and able to withstand a range of environmental conditions without needing to prepare additional enclosure in dusty places. An embedded, centrally located infrared receiver (IR) allows for easier and more flexible user control to the display.
Rigorous testing, robust protection
VMB-U series is delivered in specialized packaging which has passed a rigorous 4-step test to meet ISTA standards, ensuring the display is protected from any potential damage during transit. This provides peace of mind for businesses that the display is ready to function immediately after delivery.
Products specifications
| Attribute name |
Attribute value |
|
Width
|
47.8" |
|
Depth
|
2.88" |
|
Height
|
26.9" |
|
Weight
|
46.7 lbs |
|
Orientation
|
Horizontal/Vertical |
|
Panel mounting interface
|
600 x 400 mm |
|
Placement supported
|
Indoor |
|
VESA mounting
|
Yes |
|
DVI port
|
Yes |
|
HD type
|
Full HD |
|
Native aspect ratio
|
16:9 |
|
Display brightness
|
500 cd/m² |
|
Power consumption (standby)
|
0.5 W |
|
HDMI version
|
2.0 |
|
HDCP
|
Yes |
|
Display technology
|
LED |
|
Contrast ratio (typical)
|
1200:1 |
|
DisplayPorts quantity
|
1 |
|
DVI-D ports quantity
|
1 |
|
DisplayPort version
|
1.2 |
|
Viewing angle, horizontal
|
178 ° |
|
Viewing angle, vertical
|
178 ° |
|
Pixel pitch
|
0.0248 x 0.0248" |
|
Bezel width (top)
|
0.0886" |
|
Bezel width (bottom)
|
0.0492" |
|
Horizontal scan range
|
62.7 - 72.3 kHz |
|
Vertical scan range
|
57 - 63 Hz |
|
Color gamut
|
72 % |
|
HDCP version
|
2.2 |
|
HDMI input ports quantity
|
2 |
|
Contrast ratio (dynamic)
|
45000:1 |
|
Energy efficiency class (SDR)
|
G |
|
Energy consumption (SDR) per 1000 hours
|
165 kWh |
|
Operating hours (hours/days)
|
24/7 |
|
DisplayPorts in
|
1 |
|
Native refresh rate
|
60 Hz |
|
RS-232 input ports
|
1 |
|
RS-232 output ports
|
1 |
|
Energy efficiency class (HDR)
|
Not available |
|
Haze rate
|
25 % |
|
IR input ports quantity
|
1 |
|
Response Time
|
0.008 s |
|
Panel Type
|
IPS |
|
Audio Input
|
Yes |
|
Audio Output
|
Yes |
|
Certification
|
FCC (USA) Part 15, Subpart B Class ACE (Europe) : EN55032 : 2012 or 2015 ? EN55024:2010 or EN 55035:2017VCCI (Japan) : VCCI CISPR32:2016 Class BKCC/EK (Korea) : Tuner : KN13 / KN20Tunerless : KN22 / KN24BSMI (Taiwan) : CNS13438 ( ITE EMI ) Class A / CNS14 |
|
Product color
|
Black |
|
Wall mountable
|
Yes |
|
Display resolution
|
1920 x 1080 pixels |
|
Package width
|
55" |
|
Package depth
|
10.1" |
|
Package height
|
33.2" |
|
Package weight
|
63.5 lbs |
|
Mounting kit
|
Yes |
|
Ethernet LAN
|
Yes |
|
Ethernet LAN (RJ-45) ports
|
1 |
|
HDMI ports quantity
|
2 |
|
USB ports quantity
|
1 |
|
USB port
|
Yes |
|
Power consumption (typical)
|
220 W |
|
AC input frequency
|
50 - 60 Hz |
|
AC input voltage
|
100 - 240 V |
|
Operating temperature (T-T)
|
0 - 40 °C |
|
Storage temperature (T-T)
|
10 - 90 °C |
|
Display diagonal
|
55" |
