Width | 17.3" |
Depth | 13.8" |
Height | 1.73" |
Weight | 10.9 lbs |
Switch Type | Managed |
Stackable | Yes |
Heat dissipation | 764.18 BTU/h |
Built-in processor | Yes |
Installed SFP modules quantity | 0 |
Installed SFP+ modules quantity | 0 |
Switching capacity | 128 Gbit/s |
Power supply included | Yes |
Throughput | 95.23 Mpps |
Rack mount kit | Yes |
Number of VLANs | 4094 |
SFP+ module slots quantity | 2 |
Power over Ethernet (PoE) power per port | 60 W |
Static route | Yes |
Combo SFP ports quantity | 2 |
Port mirroring | Yes |
Broadcast storm control | Yes |
DHCP features | DHCP server, DHCP snooping, DHCP relay, DHCP client |
DoS attack prevention | Yes |
Link aggregation | Yes |
Access Control List (ACL) | Yes |
SSH/SSL support | Yes |
IGMP snooping | Yes |
Number of queues | 8 |
IP routing | Yes |
Rate limiting | Yes |
Number of static routes | 8000 |
IP-MAC-Port binding | Yes |
Number of multicast groups filtered | 4000 |
sFlow | Yes |
Physical stacking (units) | 4 |
Queue scheduling algorithms | SP, Weighted Round Robin (WRR) |
GARP VLAN Registration Protocol (GVRP) | Yes |
Loop protection | Yes |
ARP inspection | Yes |
BPDU filtering/protection | Yes |
IPv4 & IPv6 features | IPv6 ping, IPv6 Telnet, Dual stack IPv4/IPv6 |
Authentication | Guest VLAN, Port-based authentication, Web-based authentication |
Active link detection | Yes |
Head-of-line (HOL) blocking | Yes |
Access Control List (ACL) rules | 2000 |
Cable length detection | Yes |
Telnet | Yes |
Authentication type | IEEE 802.1x, RADIUS |
Number of IP interfaces | 256 |
Root protection | Yes |
Certification | UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A |
Form factor | 1U |
Product color | Black |
Flow control support | Yes |
Internal memory | 512 MB |
Number of fans | 2 fan(s) |
LED indicators | Yes |
Noise level | 52.9 dB |
Mean time between failures (MTBF) | 244654 h |
Cables included | AC, Serial |
Console port | RJ-45 |
Fiber optic connector | SFP+ |
Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
Reset button | Yes |
Processor frequency | 800 MHz |
Firmware upgradeable | Yes |
Quick start guide | Yes |
Rack mounting | Yes |
MAC address table | 64000 entries |
USB 2.0 ports quantity | 1 |
Basic switching RJ-45 Ethernet ports quantity | 24 |
Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Power over Ethernet plus (PoE+) ports quantity | 24 |
Gigabit Ethernet (copper) ports quantity | 24 |
AC input frequency | 47/63 Hz |
AC input voltage | 100 - 240 V |
Number of power supply units | 1 |
Total Power over Ethernet (PoE) budget | 195 W |
Power consumption (max) | 268.3 W |
Multicast support | Yes |
Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
Jumbo frames support | Yes |
Jumbo frames | 9000 |
10G support | Yes |
Quality of Service (QoS) support | Yes |
VLAN support | Yes |
Spanning tree protocol | Yes |
Virtual LAN features | Private VLAN, Voice VLAN, Tagged VLAN, Protocol-based VLAN, MAC address-based VLAN, IP subnet–based VLAN |
Operating temperature (T-T) | 0 - 50 °C |
Storage temperature (T-T) | -20 - 70 °C |
Operating relative humidity (H-H) | 10 - 90 % |
Storage relative humidity (H-H) | 10 - 90 % |
Packet buffer memory | 12 MB |
Flash memory | 256 MB |
Web-based management | Yes |
Switch layer | L2/L3 |
Security algorithms | 802.1x RADIUS, HTTPS, MD5, SNMP, SSH, SSL/TLS |
System event log | Yes |
Power over Ethernet (PoE) | Yes |
