Color
|
No |
|
Width
|
16.5" |
|
Depth
|
14.8" |
|
Height
|
11.4" |
|
Weight
|
25.6 lbs |
|
Display
|
LCD |
|
Quick installation guide
|
Yes |
|
Built-in processor
|
Yes |
|
Control type
|
Buttons |
|
Standard interfaces
|
Ethernet, USB 2.0 |
|
Warranty card
|
Yes |
|
Maximum internal memory
|
256 MB |
|
Market positioning
|
Business |
|
Power consumption (standby)
|
6.1 W |
|
ISO A-series sizes (A0...A9)
|
A4, A5, A6 |
|
HP segment
|
Business |
|
Pallet dimensions (W x D x H)
|
47.2 x 39.4 x 97.7" |
|
Number of layers per pallet
|
5 pc(s) |
|
Number of cartons per pallet layer
|
6 pc(s) |
|
Print speed (black, normal quality, A4/US Letter)
|
43 ppm |
|
Time to first page (black, normal)
|
5.8 s |
|
Maximum duty cycle
|
100000 pages per month |
|
Number of print cartridges
|
2 |
|
Page description languages
|
PostScript 3, PDF 1.7, PCLm, PWG, URF, PCL 5, PCL 6 |
|
Recommended duty cycle
|
1500 - 6000 pages per month |
|
Total input capacity
|
650 sheets |
|
Total output capacity
|
250 sheets |
|
Multi-Purpose tray
|
Yes |
|
Multi-Purpose tray input capacity
|
100 sheets |
|
Maximum number of input trays
|
5 |
|
Maximum input capacity
|
1200 sheets |
|
Maximum output capacity
|
250 sheets |
|
Paper tray media types
|
Plain paper, Bond paper, Recycled paper, Envelopes, Card stock, Labels, Transparencies, Heavy paper, Lightweight paper, Rough paper, Letterhead |
|
Non-ISO print media sizes
|
Hagaki card, Oficio, 16K |
|
JIS B-series sizes (B0...B9)
|
B5, B6 |
|
Envelopes sizes
|
B5, C5, DL |
|
Sound pressure level (printing)
|
54 dB |
|
Duplex printing mode
|
Auto |
|
Mobile printing technologies
|
Mopria Print Service, HP ePrint, Apple AirPrint |
|
Power consumption (printing)
|
660 W |
|
Printing
|
Mono printing |
|
Power consumption (PowerSave)
|
0.7 W |
|
Print resolution black
|
600 x 600 DPI |
|
ISO B-series sizes (B0...B9)
|
B5 |
|
Paper tray media weight
|
60 - 200 g/m² |
|
Print margins (top, bottom, right, left)
|
0.197" |
|
Power consumption (ready)
|
6.1 W |
|
Power consumption (off)
|
0.1 W |
|
Energy Star Typical Electricity Consumption (TEC)
|
1.623 kWh/week |
|
Display number of lines
|
2 lines |
|
Pallet dimensions (W x D x H) (imperial)
|
47.2 x 39.4 x 97.7" |
|
Harmonized System (HS) code
|
84433210 |
|
UNSPSC-code
|
43212105 |
|
Paper tray 2 input capacity
|
550 sheets |
|
Electromagnetic compatibility
|
CISPR 22:2008 (International) - Class A; EN 55022:2010 (EU) - Class A; EN 61000-3-2:2006+A1:2009+A2:2009; EN 61000-3-3:2008; EN 55024:2010; EMC Directive 2004/108/EC; Other EMC approvals as required by individual countries |
|
Custom media width
|
3 - 8.5" |
|
Custom media length
|
5 - 14" |
|
Custom media sizes
|
Tray 1: 76.2 x 127 mm to 215.9 x 355.6 mm; Tray 2, Tray 3: 105 x 148 mm to 215.9 x 355.6 mm |
|
ISO C-series sizes (C0...C9)
|
C5 |
|
Photo paper sizes
|
10x15 cm |
|
Secure printing
|
Yes |
|
Printer fonts
|
Scalable, TrueType |
|
Paper tray 1 input capacity
|
100 sheets |
|
Replacement cartridges
|
HP 87A Black Original LaserJet Toner Cartridge (~8,550 yield) CF287A, HP 87X Black Original LaserJet Toner Cartridge (~18,000 yield) CF287X |
|
Sound power level (printing)
|
6.8 dB |
|
HP Auto-On/Auto-Off
|
Yes |
|
HP Security tools
|
Embedded Web Server: password-protection, secure browsing via SSL/TLS; Network: enable/disable network ports and features, SNMPv1 & SNMPv2 community password change; HP ePrint: HTTPS with certificate validation, HTTP Basic Access Authentication, SASL authentication; Firewall and ACL; SNMPv3, 802.1X, Secure Boot |
|
Recommended operating temperature range (T-T)
|
17.5 - 25 °C |
|
Envelope feeder
|
No |
|
Acoustic power emissions (ready)
|
40 dB |
|
Acoustic pressure emissions bystander (ready)
|
25 dB |
|
Typical electricity consumption (TEC) number
|
Blue Angel: 1.623 kWh/Week; Energy Star 3.0: 0.562 kWh/Week |
|
Recommended system requirements
|
Compatible OS (see "Compatible Operating Systems"); CD-ROM drive or Internet connection (for software installation); Dedicated USB connection or a network connection (wired or wireless); 1 GB available hard disk space; For operating system minimum hardware requirements; see the OS manufacturer.
Compatible OS (see "Compatible Operating Systems"); Internet connection (for software installation); Dedicated USB connection or a network connection (wired or wireless); 1 GB available hard disk space; For operating system minimum hardware requirements; see the OS manufacturer. |
|
Box contents
|
HP LaserJet Pro MFP M501dn; preinstalled introductory HP LaserJet Toner cartridge (Black: ~6000 pages); In-box documentation (Installation Guide, Getting Started Guide, User's Guide, Support Flyer, Warranty Guide); Printer documentation and software on CD-ROM; Software drivers and documentation on CD-ROM; Power cord |
|
Sustainable technologies and materials
|
ENERGY STAR certified; EPEAT rated |
|
Recommended humidity operating range
|
30 - 70 % |
|
Compliance certificates
|
CECP |
|
Total carbon footprint (kg of CO2e)
|
150 |
|
Carbon emissions, manufacturing (kg of CO2e)
|
91 |
|
Carbon emissions, logistics (kg of CO2e)
|
4 |
|
Carbon emissions, end-of-life (kg of CO2e)
|
14 |
|
Total carbon emissions, w/o use phase (kg of CO2e)
|
40 |
|
HP GTIN (EAN/UPC)
|
889296258483. 198415553850. 889296258506 |
|
HP GTIN (EAN/UPC) with options
|
(201) 889296258483; (ABU) 198415553850; (BGJ) 889296258506 |
|
Manufacturer warranty
|
NA/EMEA: One-year, next-business day, onsite warranty. Warranty and support options vary by product, country and local legal requirements. Go to hp.com/support to learn about HP award winning service and support options in your region; AP: One year return to bench |
|
Duplex Printing
|
Yes |
|
Network Ready
|
Yes |
|
Country of Origin
|
Brazil |
|
Certification
|
CISPR 22:2008 (International) - Class A; EN 55022:2010 (EU) - Class A; EN 61000-3-2:2006+A1:2009+A2:2009; EN 61000-3-3:2008; EN 55024:2010; EMC Directive 2004/108/EC; Other EMC approvals as required by individual countries |
|
Built-in display
|
Yes |
|
Product color
|
White |
|
Sustainability certificates
|
ENERGY STAR, EPEAT Silver |
|
Sustainability compliance
|
Yes |
|
Internal memory
|
256 MB |
|
Power supply type
|
Built-in power supply |
|
Maximum resolution
|
600 x 600 DPI |
|
Linux operating systems supported
|
Fedora 17, Fedora 18, Linux Mint 13, Linux Mint 17, Debian 6.0, Debian 7.0, Ubuntu 10.04, Ubuntu 11.10, Ubuntu 12.04, Ubuntu 12.10, Ubuntu 13.04, Ubuntu 13.10, Ubuntu 14.04, Ubuntu 14.10 |
|
Package width
|
19.6" |
|
Package depth
|
15.7" |
|
Package height
|
18.3" |
|
Package weight
|
32 lbs |
|
Bundled software
|
For Windows OS; HP Software Installer/Uninstaller, HP PCL 6 Printer Driver, HP Device Experience (DXP), HP Update, Product Registration Assist, HP Web Services Assist (HP Connected), Online user manuals, HP Device Toolbox, HP Product Improvement Study ;For Mac OS; Welcome Screen, (Directs users to HP.com or OS App Source for LaserJet Software) |
|
User guide
|
Yes |
|
Pallet weight
|
1006.9 lbs |
|
Quantity per pallet
|
30 pc(s) |
|
Manual
|
Yes |
|
Cables included
|
AC |
|
Printing colors
|
Black |
|
Print technology
|
Laser |
|
Cabling technology
|
10/100Base-T(X) |
|
Ethernet LAN
|
Yes |
|
Processor frequency
|
1500 MHz |
|
Compatible operating systems
|
Windows OS compatible with In-Box Driver: Windows 10 all 32-bit/64-bit editions (excluding RT OS for tablets), Windows 8/8.1 all 32-bit/64-bit editions (excluding RT OS for tablets), Windows 7 all 32-bit/64-bit editions, Windows Vista all 32-bit editions (Home Basic, Premium, Professional, etc); Windows OS compatible with Universal Print Driver (from HP.com): Windows 10 all 32-bit/64-bit editions (excluding RT OS for tablets), Windows 8/8.1 all 32-bit/64-bit editions (excluding RT OS for tablets), Windows 7 all 32-bit/64-bit editions, Windows Vista all 32-bit/64-bit editions (Home Basic, Premium, Professional, etc); Mac OS (HP print drivers available from http://www.HP.com and Apple Store): OS X 10.10 Yosemite, OS X 10.9 Mavericks, OS X 10.8 Mountain Lion, OS X 10.7 Lion; Mobile OS (In-OS drivers): iOS, Android, Windows 8/8.1/10 RT; Linux OS (In-OS HPLIP): SUSE Linux (12.2, 12.3, 13.1), Fedora (17, 18, 19, 20), Linux Mint (13, 14, 15, 16, 17), Boss (3.0, 5.0), Ubuntu (10.04, 11.10, 12.04, 12.10, 13.04, 13.10, 14.04, 14.10), Debian (6.0.x, 7.x); Other OS: UNIX |
|
USB port
|
Yes |
|
AC input frequency
|
50 Hz |
|
AC input voltage
|
200 - 240 V |
|
Ethernet LAN data rates
|
1000 Mbit/s |
|
Wi-Fi
|
No |
|
Operating temperature (T-T)
|
15 - 32.5 °C |
|
Storage temperature (T-T)
|
-20 - 60 °C |
|
Operating relative humidity (H-H)
|
10 - 80 % |
|
Storage relative humidity (H-H)
|
10 - 90 % |
|
Windows operating systems supported
|
Windows Vista Home Basic x64, Windows Vista Home Basic, Windows Vista Home Premium x64, Windows Vista Home Premium, Windows Vista x64, Windows Vista, Windows 7 Professional x64, Windows 7 Professional, Windows 7 Home Premium x64, Windows 7 Home Premium, Windows 7 Home Basic x64, Windows 7 Home Basic, Windows 7 x64, Windows 7, Windows 8 x64, Windows 8, Windows 8.1 x64, Windows 8.1, Windows 10 x64, Windows 10 |
|
Mac operating systems supported
|
Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yosemite, MacOS |
|
Other operating systems supported
|
iOS, Linux, Android |
|
Security algorithms
|
SNMPv3, SSL/TLS, SNMPv2, SNMP, HTTPS |
|
Maximum ISO A-series paper size
|
A4 |
