The Veritas NetBackup Flex deployment mode running on a 5250 Appliance provides ransomware resilience and the capacity and performance to consolidate smaller NetBackup domains into a single appliance.
Based on container technology, the NetBackup Flex deployment mode extends NetBackup data protection with multi-tenant capabilities to reduce data center costs, improve management efficiency and protect against ransomware and security threats.
Products specifications
Attribute name | Attribute value |
---|
Width | 19" |
Depth | 31.3" |
Height | 3.5" |
Type | NAS |
Supported storage drive interfaces | Serial Attached SCSI (SAS) |
Processor generation | 2nd Generation Intel® Xeon® Scalable |
Device class | Large Enterprise Business |
Maximum RAM supported | 512 GB |
Number of processors supported | 2 |
Hot spare | Yes |
Chassis type | Rack (2U) |
Internal memory | 256 GB |
Internal memory type | DDR4 |
Memory form factor | RDIMM |
Cooling type | Active |
LED indicators | Yes |
Noise level | 70 dB |
Fiber optic connector | SFP |
Fiber ports quantity | 2 |
Ethernet LAN | Yes |
Backup function | Yes |
Processor frequency | 2.2 GHz |
Ethernet LAN (RJ-45) ports | 4 |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
VGA (D-Sub) ports quantity | 1 |
USB port | Yes |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
AC input frequency | 50/60 Hz |
AC input voltage | 100-240 V |
Redundant power supply (RPS) support | Yes |
Power supply location | Built-in |
Ethernet LAN data rates | 1000,10000 Mbit/s |
Operating temperature (T-T) | 10 - 35 °C |
Storage temperature (T-T) | -25 - 70 °C |
Operating relative humidity (H-H) | 20 - 80 % |
Storage relative humidity (H-H) | 8 - 90 % |
Operating altitude | -1181.1 - 118110.2" |
Memory slots | 16 |
RAID support | Yes |
RAID levels | 1, 6 |
Storage drives installed | Yes |
Total installed storage capacity | 206 TB |
Installed storage drive type | HDD |
Supported storage drive types | HDD & SSD |
Hot-swap drive bays | Yes |
Storage drive interface | Serial Attached SCSI (SAS) |
Storage drive size | 3.5" |
Storage drive sizes supported | 3.5" |
Web-based management | Yes |
Processor family | Intel Xeon Silver |
Processor manufacturer | Intel |
Processor model | 4214 |
Processor boost frequency | 3.2 GHz |
Processor cores | 12 |
Processor threads | 24 |
Processor cache | 16.5 MB |
