Intuitive LCD interface
Provides clear and accurate information in multiple languages with the ability to configure the
UPS locally with easy to use navigation keys.
Predictive replace battery date
Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
Green mode
Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
Energy meter
Provides actual kilowatt hours of usage for energy conscious users.
Sequenced shutdown and restart
Configure select outlet groups to shut down and turn on in a pre-determined order (for UPSs with switched outlet groups).
Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Products specifications
| Attribute name |
Attribute value |
|
Width
|
7.76" |
|
Depth
|
21.4" |
|
Height
|
17.1" |
|
Weight
|
115.7 lbs |
|
Battery Capacity
|
816 VAh |
|
Automatic Voltage Regulation (AVR)
|
Yes |
|
Battery Recharge Time
|
3 h |
|
Emergency Power Off (EPO)
|
Yes |
|
Input Frequency
|
50/60 Hz |
|
Display
|
LCD |
|
Cable Length
|
72" |
|
Display Type
|
LCD |
|
Quick installation guide
|
Yes |
|
Battery life (max)
|
5 year(s) |
|
Automatic battery test
|
Yes |
|
UPS topology
|
Line-Interactive |
|
Cold start
|
Yes |
|
Number of output IEC jumpers
|
2 |
|
Hold time (max)
|
2 ms |
|
Software CD
|
Yes |
|
Auto-restart
|
Yes |
|
SmartSlot
|
Yes |
|
Compliance certificates
|
RoHS |
|
Certification
|
CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, VDE, REACH, PEP, EOLI |
|
Form factor
|
Tower |
|
Product color
|
Black |
|
Sustainability certificates
|
Green Premium |
|
LED indicators
|
Status |
|
Output power
|
2700 W |
|
Noise level
|
53 dB |
|
Audible alarm(s)
|
Yes |
|
Surge energy rating
|
365 J |
|
Input operation voltage (min)
|
151 V |
|
Input operation voltage (max)
|
302 V |
|
Efficiency
|
98.1 % |
|
Waveform
|
Sine |
|
Surge protection
|
Yes |
|
Package width
|
15" |
|
Package depth
|
30" |
|
Package height
|
27.5" |
|
Package weight
|
140.4 lbs |
|
Quantity per pallet
|
9 pc(s) |
|
Cables included
|
RS-232, USB cable |
|
Nominal output voltage
|
230 V |
|
AC outlets quantity
|
9 AC outlet(s) |
|
AC outlet types
|
C13 coupler, C19 coupler |
|
Power plug
|
C20 coupler |
|
USB port
|
Yes |
|
Nominal input voltage
|
230 V |
|
Output power capacity
|
3 kVA |
|
Operating temperature (T-T)
|
0 - 40 °C |
|
Storage temperature (T-T)
|
-15 - 45 °C |
|
Operating relative humidity (H-H)
|
0 - 95 % |
|
Storage relative humidity (H-H)
|
0 - 95 % |
|
Operating altitude
|
0 - 118110.2" |
|
Non-operating altitude
|
0 - 590551.2" |
|
Battery technology
|
Sealed Lead Acid (VRLA) |
|
Typical backup time at full load
|
5.1 min |
|
Typical backup time at half load
|
17.2 min |
|
Hot-swap battery
|
Yes |
