Lenovo 4XB7A82853 internal solid state drive 960 GB U.3 PCI Express 4.0 NVMe 3D TLC NAND

Lenovo 4XB7A82853. SSD capacity: 960 GB, SSD form factor: U.3, Component for: Universal

Manufacturers: Lenovo , LENOVO DATA CENTER

SKU: 7126946

Manufacturer part number: 4XB7A82853

UPC: 0889488641987

Price: $1,041.86

Qty:

The ThinkSystem 7450 PRO Read Intensive NVMe SSDs are general-purpose yet high-performance family of NVMe solid-state drives. They are engineered for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.

Overview
Specifications
Contact Us

Products specifications

Attribute name	Attribute value
Width	2.76"
Depth	3.94"
Height	0.276"
Weight	2.47 oz
Maximum operating altitude	120078.7"
Non-operating shock	1500 G
Vibration resistance	20 G
Read latency	80 µs
Write latency	15 µs
Uncorrectable Bit Error Rate (UBER)	< 1 per 10^17 bits read
Design
Certification	CE (Europe): EN55032, EN55024 Class B, RoHS FCC: CFR Title 47, Part 15, Class B UL/cUL: approval to UL-60950-1, 2nd Edition, IEC 60950-1:2005 (2nd Edition); EN 60950-1 (2006) + A11:2009+ A1:2010 + A12:2011 + A2:2013 BSMI (Taiwan): approval to CNS 13438, Class B, CNS 15663 RCM (Australia, New Zealand): AS/NZS CISPR32 Class B KC RRL (Korea): approval to KN32 Class B, KN 35 Class B W.E.E.E.: Compliance with EU WEEE directive 2012/19/EC. TUV (Germany): approval to IEC60950/EN60950 VCCI (Japan): 2015-04 Class B IC (Canada): ICES-003 Class B Morocco: EN55032, EN55024 Class B UkrSEPRO (Ukraine): EN55032 Class B, IEC60950/EN60950, RoHS (Resolution 2017 No. 139) UKCA (UK): SI 2016/1091 Class B and SI 2012/3032 RoHS
Features
Component for	Universal
ECC	Yes
Hot-swap	Yes
Mean time between failures (MTBF)	2000000 h
SSD capacity	960 GB
Memory type	3D TLC NAND
Random read (4KB)	530000 IOPS
S.M.A.R.T. support	Yes
NVMe	Yes
Random write (4KB)	85000 IOPS
SSD form factor	U.3
Ports & interfaces
Interface	PCI Express 4.0
Power
Power consumption (read)	10 W
Power consumption (write)	7 W
Operational conditions
Operating temperature (T-T)	0 - 70 °C
Storage temperature (T-T)	-40 - 85 °C
