Cisco 6132 processor 2.6 GHz 19.25 MB L3 Tray

Cisco 6132. Processor family: Intel® Xeon® Gold, Processor socket: LGA 3647 (Socket P), Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 768 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: S4S. Processor package size: 76mm x 56.5mm. Maximum internal memory: 768 GB, Maximum internal memory: 786432 MB
Manufacturers: Cisco , Cisco Systems
SKU: 11619875
Manufacturer part number: HX-CPU-6132
MSRP: $8,280.20
$4,583.09
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.

Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.

Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Products specifications
Attribute nameAttribute value
Maximum Memory768 GB
Maximum internal memory786432 MB
On-board graphics cardNo
Discrete graphics card modelNot available
Supported instruction setsSSE4.2, AVX, AVX 2.0, AVX-512
Memory clock speeds supported by processor2666 MHz
Tcase86 °C
Processor generation1st Generation Intel® Xeon® Scalable
Processor base frequency2.6 GHz
Intel® vPro™ Platform EligibilityYes
Discrete graphics cardNo
Intel® Optane™ Memory ReadyNo
Cooler includedNo
Harmonized System (HS) code85423119
Market segmentServer
StatusLaunched
Processor brand nameIntel Xeon Gold Intel Xeon Gold Processor
Last change63903513
Product familyIntel Xeon Processors
Export Control Classification Number (ECCN)5A992C
Supported memory typesDDR4-SDRAM
Launch dateQ3'17
PCI Express CEM revision3.0
Intel® Transactional Synchronization ExtensionsYes
Intel Turbo Boost Max Technology 3.0No
Intel® Speed Shift TechnologyYes
AVX-512 Fused Multiply-Add (FMA) units2
Intel® Run Sure Technology version1.00
Intel® Volume Management Device (VMD) version1.00
Mode-based Execute Control (MBE) version1.00
Number of UPI links3
Intel® Volume Management Device (VMD)Yes
Intel® Run Sure TechnologyYes
Mode-based Execute Control (MBE)Yes
Intel® Speed Shift Technology version1.00
Memory speed (max)2666 MHz
Features
Component forServer/workstation
ECCYes
Memory channelsHexa-channel
Product typeProcessor
Packaging data
Package typeTray
Other features
Processor ARK ID123541
Processor
Processor familyIntel® Xeon® Gold
Processor manufacturerIntel
Processor model6132
Processor boost frequency3.7 GHz
Processor cores14
Processor threads28
Processor cache19712 KB
PCI Express slots version3.0
Processor cache typeL3
Processor codeSR3J3
Processor codenameSkylake
Processor lithography14 nm
Processor operating modes64-bit
Processor package size76mm x 56.5mm mm
Processor socketLGA 3647 (Socket P)
ScalabilityS4S
SteppingH0
Thermal Design Power (TDP)140 W
On-board graphics card modelNot available
Maximum internal memory supported by processor768 GB
Conflict-Free processorYes
Processor special features
Embedded options availableNo
Enhanced Intel SpeedStep TechnologyYes
Execute Disable BitYes
Intel 64Yes
Intel Trusted Execution TechnologyYes
Intel TSX-NIYes
Intel TSX-NI version1.00
Intel Virtualization Technology (VT-x)Yes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Turbo Boost Technology2.0
Maximum number of PCI Express lanes48
Memory types supported by processorDDR4-SDRAM
*
*
*
